Mx341 Avr Manual Voltage Regulator
MX341 is a two phase sensed Automatic Voltage. Regulator and forms part of the excitation system for a brush-less generator. Excitation power is derived from a. NEWAGE MX341 AVR, REPLACEMENT. Same fit form and function as the Original Newage MX341 Generator Automatic Voltage Regulator Operation Manual.
EA341 EA341 Permanent Magnet Generator Automatic Voltage Regulator EA341 Permanent Magnet Generator type voltage regulator is a compatible replacement for Newage Stamford MX341 and Onan 305-0846. All manufacturer names and numbers are used for reference purpose only and do not imply that any part is the product of these manufacturer. Features. Voltage regulation 5 Vac External Volts Adjustment +/-10% with 1 kΩ 1 watt trimmer Unit Power Dissipation Max. 12 watts Thermal Drift 0.05% per °C change in AVR ambient Soft Start Ramp Time 3 seconds Analogue Input Max.
Input +/-5 Vdc Sensitivity 1V for 5% generator volts Input Resistance 1 kΩ Droop Input Burden 10 ohms Max. Sensitivity 0.07A for 5% droop (PF=0) Max. Input 0.33A Under Frequency Protection (Factory Setting) Set Point 95% Hz Slope 170% down to 30 Hz Current Limit Input Burden 10 ohms Sensitivity Range 0.5A to 1A Over Voltage Detector Input Set Point 300V Time Delay 1 second (fixed) CB Trip Coil Volts 10 to 30 Vdc / 0.5 Amp Over Excitation Protection Set Point 90 Vdc Time Delay 10 seconds (fixed) Environment Operating Temperature -40 to +70 °C Storage Temperature -40 to +85 °C Relative Humidity Max. 95% Vibration 3.3Gs @ 100 to 2K Hz AVR Control Functions VOLT Voltage adjustment STAB Stability adjustment U/F Setting under frequency protection knee point DROOP To set the Droop to 5% at PF=0 TRIM To optimize analogue input sensitivity EXC TRIP Over excitation trip level set DIP Hz related voltage DIP set Dimension 150.0 (L) x 135.0 (W) x 48.0 (H) mm Weight 394 g +/-2% Diagram and Dimensions.
Mx341 automatic voltage regulator (avr) - Frontier Power MX341 AUTOMATIC VOLTAGE REGULATOR (AVR) SPECIFICATION, INSTALLATION AND ADJUSTMENTS General description Technical specification MX341 is a two phase sensed Automatic Voltage Regulator and forms part of the excitation system for a brush-less generator. Excitation power is derived from a three-phase permanent magnet generator (PMG), to isolate the AVR control circuits from the effects of nonlinear loads and to reduce radio frequency interference on the generator terminals. Sustained generator short circuit current is another feature of the PMG system. The AVR senses the voltage in the main generator winding and controls the power fed to the exciter stator and hence the main rotor to maintain the generator output voltage within the specified limits, compensating for load, speed, temperature and power factor of the generator. Soft start circuitry is included to provide a smooth controlled build up of generator output voltage. A frequency measuring circuit continually monitors the shaft speed of the generator and provides under-speed protection of the excitation system by reducing the generator output voltage proportionally with speed below a pre-settable threshold. A further enhancement of this feature is an adjustable volts per Hertz slope to improve engine recovery time on turbo charged engines.
Soft start circuitry is included to provide a smooth controlled build up of generator output voltage. Uncontrolled excitation is limited to a safe period by internal shutdown of the AVR output device. This condition remains latched until the generator has stopped. Provision is made for the connection of a remote voltage trimmer, allowing the user fine control of the generator's output.
Mx341 Avr Manual
An analogue input is provided allowing connection to a Newage Power Factor controller or other external devices with compatible output. Repair manual sx 65 2018. The AVR has the facility for droop CT connection, to allow parallel running with other similarly equipped generators. SENSING INPUT Voltage 190-264V ac max, 1 phase, 2 wire Frequency 50-60 Hz nominal POWER INPUT (PMG) Voltage 140-220V ac max, 3 phase, 3 wire Current 3A/phase Frequency 100-120 Hz nominal OUTPUT Voltage max 120V dc Current continuous 2.7 A Intermittent 6A for 10 secs.
